Motor Power

• Normal Duty (ND): 15 kW / 20 hp (for applications with light overload
• Heavy Duty (HD): 11 kW / 15 hp (for applications with significant overload
• Supply Voltage: 380...460 V AC, 3-phase
• Supply Frequency: 50...60 Hz
• Output Frequency: 0.0001...500 Hz (0.5 kHz)
• Continuous Output Current:
• Normal Duty: 31.7 A (at 4 kHz)
• Heavy Duty: 23.5 A (at 4 kHz)

Apparent Power:

• Normal Duty: 20.7 kVA (at 460 V)
• Heavy Duty: 16.6 kVA (at 460 V)
• Protection Rating: IP20 (for protection against solid objects larger than 12.5mm; no protection against liquids)
• Cooling: Forced convection (with derating at higher temperatures)
• Communication: Integrated Modbus serial protocol
• Mounting: Can be wall-mounted in a vertical position with a +/- 10-degree tolerance.
